ASRock H610M-HDV/M.2 R2.0 Super Alloy Intel 1700 Socket Motherboard

ASRock H610M-HDV/M.2 R2.0 Super Alloy Intel LGA 1700 Motherboard

The ASRock H610M-HDV/M.2 R2.0 is a robust Micro-ATX motherboard designed for 12th, 13th, and 14th Gen Intel Core processors. Featuring DDR4 support, PCIe 4.0, Ultra M.2, multiple display outputs, and advanced protection technologies, this board is ideal for compact desktops, workstations, and productivity setups.

• CPU Support: Intel 12th, 13th & 14th Gen Core Processors (LGA1700)
• Power Design: 6+1+1 Phase, Digi Power with Premium Power Choke
• Memory:
  • 2 x DDR4 DIMM slots, non-ECC, unbuffered, up to 3200 MHz
  • Max system memory: 64GB
  • Supports Intel XMP 2.0
• Chipset: Intel H610
• Expansion Slots:
  • 1 x PCIe 4.0 x16
  • 1 x PCIe 3.0 x1
• Storage:
  • 1 x Ultra M.2 (PCIe Gen3 x4, 32 Gb/s, supports 2242/2260/2280)
  • 4 x SATA3 6.0 Gb/s connectors
• Graphics Outputs: HDMI 4K @60Hz, DisplayPort 1.4 (up to 8K @60Hz/5K @120Hz), D-Sub 1920x1200 @60Hz
• Audio: 7.1 CH HD Audio with Realtek ALC897 codec and surge protection
• LAN: Realtek RTL8111H Gigabit Ethernet with Wake-On-LAN, ESD, and Energy Efficient Ethernet support
• Rear I/O Ports:
  • 1 x PS/2 Mouse/Keyboard
  • 1 x D-Sub, 1 x HDMI, 1 x DisplayPort 1.4
  • 2 x USB 3.2 Gen1, 4 x USB 2.0
  • 1 x RJ-45 LAN
  • HD Audio Jacks: Line In, Front Speaker, Microphone
• Internal Connectors:
  • 1 x SPI TPM Header
  • USB 3.2 Gen1 Header (2 ports)
  • USB 2.0 Header (2 ports)
  • CPU & Chassis/Water Pump Fan Connectors (4-pin, Smart Fan Control)
  • Front Panel Audio Connector, Chassis Intrusion, Speaker Header
• Unique Features:
  • ASRock Super Alloy Design
  • Sapphire Black PCB with High-Density Glass Fabric
  • Ultra M.2 PCIe Gen3x4, Full Spike Protection, Live Update & App Shop
  • Digi Power & Premium Power Choke for stable Vcore
• Form Factor: Micro ATX (22.0 cm x 19.3 cm)
• OS Support: Microsoft Windows 10/11 64-bit
• Included Accessories: Quick Installation Guide, Support CD, I/O Shield, 2 x SATA Cables, 1 x M.2 Screw

Highlights: Multi-generation CPU support, dual-channel DDR4, PCIe 4.0 expansion, Ultra M.2 slot, 4K/8K graphics outputs, and comprehensive spike protection make this motherboard ideal for high-performance, compact desktop builds.
